Step-by-step technique videos in orthopaedic surgery
Videos
Authors
About
Chapters
0:01
Skin marking
0:13
Incision and dissection to external oblique fascia
0:23
Lateral window: expose ileum and pack
0:39
Middle window: divide external oblique fascia
0:49
Middle window: divide inguinal ligament
1:02
Middle window: expose IP muscle and femoral nerve
1:12
Middle window: expose/divide liopectineal fascia
1:50
Middle window: penrose around IP muscle
2:02
Connect lateral and middle windows under IP muscle
2:31
Medial window: expose and incise linea alba
2:41
Medial window: split rectus, enter retropubic spac
2:48
Expose pubic symphysis
2:56
Ligate corona mortis if present
3:08
Expose pelvic brim
3:25
Schanz pin into femoral neck for lateral traction
3:40
Reduce anterior column through lateral window
4:00
Clean and reduce superior ramus fracture
4:26
Clean and re-reduce anterior column
4:55
Buttress anterior column with short recon plate
5:48
Place independent anterior-to-posterior lag screw
6:25
Expose contralateral superior ramus
6:34
Contour pelvic brim plate
6:43
Anchor plate with 2 screws on contralateral ramus
7:18
Undercontoured lateral plate buttresses fracture
7:39
Irrigate and remove Schanz pin
Chapters
· 25
0:01
Skin marking
0:13
Incision and dissection to external oblique fascia
0:23
Lateral window: expose ileum and pack
0:39
Middle window: divide external oblique fascia
0:49
Middle window: divide inguinal ligament
1:02
Middle window: expose IP muscle and femoral nerve
1:12
Middle window: expose/divide liopectineal fascia
1:50
Middle window: penrose around IP muscle
2:02
Connect lateral and middle windows under IP muscle
2:31
Medial window: expose and incise linea alba
2:41
Medial window: split rectus, enter retropubic spac
2:48
Expose pubic symphysis
2:56
Ligate corona mortis if present
3:08
Expose pelvic brim
3:25
Schanz pin into femoral neck for lateral traction
3:40
Reduce anterior column through lateral window
4:00
Clean and reduce superior ramus fracture
4:26
Clean and re-reduce anterior column
4:55
Buttress anterior column with short recon plate
5:48
Place independent anterior-to-posterior lag screw
6:25
Expose contralateral superior ramus
6:34
Contour pelvic brim plate
6:43
Anchor plate with 2 screws on contralateral ramus
7:18
Undercontoured lateral plate buttresses fracture
7:39
Irrigate and remove Schanz pin
Anterior Column Acetabulum ORIF
David Rothberg
·
University of Utah
·
April 17, 2022
Trauma LE
Imaging
Pre-op
Post-op
